PB EUROFIBER CONCRETE+FLOORING

Since the 1980‘s the PB EUROFIBER brand has made a name for itself as a performance additive to improve construction materials. Our functional fibres are used to optimise product and processing properties in a wide variety of technical products including concretes, cement-based mortars, adhesives and dry-mix compounds.

PB EUROFIBER has been successfully used to enhance the fire resistance of concretes and cement mortars since the 1990‘s

Contact Person

Günter Vennewald

Phone: +49 (0) 52 42 – 595-110
Fax: +49 (0) 52 42 – 595-210
Mail: guenter.vennewald@baumhueter.de
More Contact Persons

Fibers for:

1

1

2

2

3

3

4

4

PP-Monofilament Fibres for ① Industrial floors + ② Concrete/prefabricated concrete parts

ProductFibre Diameter
μm
Fibre Length
mm
Usual Dosage
g/m³
Fibre Count
approx. 1 million/kg
Theoretical Length
approx. km/kg
CertificationsStandard packaging variants
PB EUROFIBER REF 506 20/6206600-9006003600(1, 2)600g bag; 20kg bagged goods
PB EUROFIBER REF 512 20/122012600-9003003600(1, 2)600g bag; 900g bag; 350kg Big Bags
PB EUROFIBER REF 520 20/182018600-9002003600(1, 2)900g bag; 260kg Big Bags
PB EUROFIBER PRO-MIX 32/632610002301400(1, 2, 3)1000g bag; 20kg bagged goods
PB EUROFIBER PRO-MIX 32/1232129001151400(1, 2)900g bag; 20kg bagged goods
PB EUROFIBER PRO-MIX 32/183218900701400(1, 2)600g bag; 350kg Big Bags
PB EUROFIBER MF 1217 15/1215125005005900(1, 2, 4)500g bag

PP splice film fibres for ③ screeds

ProductElementary
Fibril μm
Fibre Length
max. mm
Usual Dosage
g/m³
Fibre Count
approx. 1 million/kg
Theoretical Length
approx. km/kg
CertificationsVerpackung
PB EUROFIBER REF 31038 x 20010100014140(1, 2, 4)100g Beutel; 1000g Beutel; 35kg Karton
38 x 2001510009140(1, 2)auf Anfrage
PB EUROFIBER REF 32038 x 2002010007140(1, 2, 5)100g Beutel; 1000g Beutel

Steel screed fiber (for ③ heated screeds)

ProductFibre Length
mm
Usual Dosage
kg/m³
Standard packaging variants
PB EUROFIBER ESF 20/1,02020 kg/m³20 kg / Box

PP-Monofilament Fibres for ④ Mortar, plasters + insulation systems

ProduktbezeichnungDurchmesser μmFibre Length
max. mm
g/cm³dtex g/10000 mFaseranzahl ca. Mio/kgtheoretische Länge ca. km/kgVerpackung
PB EUROFIBER REF 502 18/217,52,21000-20002,22100450025 kg Sackware
PB EUROFIBER REF 505 18/518,34,61000-20002,4900420015 kg Sackware

PP splice film fibres

ProductElementary
Fibril μm
Fibre Length
max. mm
Fibre Count
approx. 106/kg
Theoretical Length
approx. km/kg
PB EUROFIBER REF 30338 x 2003,046140
PB EUROFIBER REF 30638 x 2006,023140

Technical Data

Multifil / Monofil FibresSplit-Film Fibres
PolymerPolypropylene (PP)Polypropylene (PP)
Fibre cross-sectionroundrectangular / flat
Fibre diameter13 - 145 μm38 x 200 μm
Fibre length2.2, 3, 4.6, 6, 12, 18 mm2, 3, 6, 10, 15, 20 mm
Elongation at breakapprox. 100 - 200 %< 12 %
Tensile strength> 220 N/mm²> 340 N/mm²
Elastic modulusapprox. 1000 N/mm²ca. 4000 - 6000 N/mm²

All information and data in this brochure are provided without engagement. We recommend evaluation of product suitability by appropriate testing before use.

Certifications

More

  • Other fibre geometries on request
  • Certifications / official approvals
    (1) DIBt certification
    (German Institute of Construction Technology)
    (Certification no.: Z-3.73-1878)
    (2) CE certified according to System 1
    (with annual third-party monitoring)
    (3) BB2G Zertifizierung nach ÖVBB Richtlinie
    (4) Avis technique CSTB
    (N 13/12-1158-N 3/08-578)
  • Packaging options
    Small bags: 50 – 5000 g / Large bags: 15 -25 kg
    Big Bags: approx. 200 -500 kg

Application Sectors

  • Concretes
  • Industrial floorings
  • Screeds
  • Precast concrete elements
  • Fire-resistant concretes
  • Mortars
  • etc.

Fibre Properties

  • Density: 0.91 g /cm³
    Lighter in weight than PAN /acrylic fibres
    (1.18 g /cm³) and glass fibres (2.6 g /cm³)
  • Resistant to alkalis
  • Chemically resistant to acids, bases, salts and most solvents
  • Outstanding dispersibility
  • Corrosion-free
  • Antistatic
  • Melting point: approx. 165 °C
  • Auto-ignition temperature: > 320 °C
  • Service temperature range: up to 120 °C

Typical Application Advantages

  • Reduction of shrinkage cracking
  • Increased green strength
  • Optimised processing properties
  • Improved freeze-thaw resistance
  • Higher impact strength
  • Increased flexural strength / tensile splitting strength
  • Improved fire resistance
    (reduction of spalling)
